292-7160 LINES GP-BOOM CYLINDERS/N GAX1-UP

Group No: 292-7160

Part Number	Part Name	Qty
6V1324	1 GROMMET	1
9F2167	2 SCREW-PURGE (3/8-24X1.164-IN)	2
6H3615	3 PLUG-PROTECTION	2
1132004	4 BOLT-SOCKET HEAD (M12X1.75X45-MM)	4
1021174	5 GUARD (10-CM EACH)
1287591	6 SUPPORT AS	1
8T4121	7 WASHER-HARD (11X21X2.5-MM THK)	2
4348214	8 SENSOR GP-PRESSURE (BOOM CYLINDER)	1
2344492	9 SUPPORT	1
2927367	10 FLANGE	1
3258858	11 HOSE AS	4
3258787	12 TUBE AS	1
4498064	13 TUBE AS	1
4487593	14 VALVE GP-PILOT (BOOM DRIFT REDUCTION)	1
3199721	15 SUPPORT AS	1
3199727	16 HOSE AS	1
3543813	17 HOSE AS	1
3543819	18 HOSE AS	1
1087550	19 CLIP	2
1488322	20 CONNECTOR AS	1
2M9780	SEAL-O-RING	1
6V8640	CONNECTOR	1
6V9746	SEAL-O-RING	1
1092013	21 GUARD (8-CM)
1P3703	22 SEAL-RECTANGULAR	10
1P3704	23 SEAL-RECTANGULAR	6
1P5767	25 FLANGE-HALF	8
5P1076	26 WASHER-HARD (13.5X30X4-MM THK)	2
6V0400	27 FLANGE-HALF	16
8T4139	28 BOLT (M12X1.75X30-MM)	14
1083819	29 BOLT-SOCKET HEAD (M12X1.75X70-MM)	4
8T4184	30 BOLT (M12X1.75X45-MM)	18
8T4194	31 BOLT (M12X1.75X50-MM)	32
8T4223	32 WASHER-HARD (13.5X25.5X3-MM THK)	64
8T4648	33 BOLT (M12X1.75X70-MM)	2
3199798	36 SUPPORT AS	1
3199719	37 SUPPORT AS	1
3302314	38 TUBE AS	1
1708553	39 BOLT-SOCKET HEAD (M12X1.75X40-MM)	4
1488353	41 ELBOW AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V9001	ELBOW	1
1488336	42 CONNECTOR AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V8636	CONNECTOR	1
1017397	43 BOLT-SOCKET HEAD (M12X1.75X50-MM)	4
8T4136	44 BOLT (M10X1.5X25-MM)	2
7G3414	45 CLIP (TAB)	1
7G3413	46 CLIP (SLOT)	1
