355-0450 MODULE GP-COOLINGS/N JFR1-UP; HBT1-UP

Group No: 355-0450 · Commonality

Part Number	Part Name	Qty
0964035	1 CLIP	1
1570670	2 CAP-DUST	1
4813470	3 CORE AS-AFTERCOOLER	1
4683847	4 CORE AS-OIL COOLER (HYDRAULIC OIL)	1
4331680	5 CORE AS-RADIATOR	1
3786187	BOSS-MOUNTING	4
3786197	COVER	4
3550468	5A PLUG-DRAIN (COOLANT)	1
3324192	5B SEAL-O-RING	1
3477614	6 FRAME AS	1
3477615	7 FRAME AS	1
3477616	8 FRAME AS	1
3477617	9 FRAME AS	1
3477620	10 MOUNT	8
3477623	11 CONNECTOR	1
3489965	12 SPRING AS-GAS (AFTERCOOLER CORE)	1
3550451	13 LATCH AS	2
3550452	14 SEAL-AIR	2
3550453	15 SEAL-AIR	1
1007740	16 RING-RETAINING	2
2331449	17 PIN	2
3550455	18 SEAL-AIR	4
3550456	19 PLATE	1
3550457	20 BRACKET AS	1
3550458	21 BRACKET AS	1
3550463	22 SEAL-AIR	1
3550454	23 SEAL-AIR	3
3550465	24 BRACKET AS	1
3550467	25 PLATE	2
3550469	27 RUBBER	2
3550470	28 FRAME AS	1
1156433	30 WASHER (11X50X6-MM THK)	8
1549023	31 VALVE-SAMPLING (COOLANT)	1
3K0360	32 SEAL-O-RING	1
5C7261	33 NUT (M8X1.25-THD)	2
5P1076	34 WASHER-HARD (13.5X30X4-MM THK)	16
5P4116	35 WASHER-HARD (8.8X20.5X2-MM THK)	2
5C9553	36 BOLT (M6X1X16-MM)	4
6V9027	37 SEAL-O-RING	1
7X7729	38 WASHER (11X25X3-MM THK)	2
8T4121	39 WASHER-HARD (11X21X2.5-MM THK)	12
8T4133	40 NUT (M10X1.5-THD)	8
8T4136	41 BOLT (M10X1.5X25-MM)	6
8T4182	42 BOLT (M10X1.5X45-MM)	4
8T4186	43 BOLT (M10X1.5X40-MM)	8
8T4192	44 BOLT (M12X1.75X25-MM)	16
8T4195	45 BOLT (M10X1.5X30-MM)	2
8T4223	46 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4956	47 BOLT (M12X1.75X35-MM)	2
9X8256	48 WASHER (6.6X12X2-MM THK)	4
7Y1976	49 HOSE-WATER (22-CM)
3550461	50 SEAL-AIR	1
3550459	51 SEAL-AIR	1
