System And Components
375-3166 TURBOCHARGER GPS/N D8T1-UP
Group No: 375-3166 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1015115 | 1 STUD (M10X1.5X40-MM) | 4 | |
| 1031912 | 2 STUD (M10X1.5X30-MM) | 4 | |
| 1068916 | 3 BOLT (M6X1X16-MM) | 2 | |
| 1243815 | 4 BOLT (M8X1.25X16-MM) | 6 | |
| 1978418 | 5 GASKET | 1 | |
| 2235664 | 6 BELLOWS | 1 | |
| 2412634 | 7 CLAMP-V BAND | 3 | |
| 2780017 | 8 GASKET | 2 | |
| 3293723 | 9 GASKET | 1 | |
| 3435910 | 10 CLAMP-V BAND | 1 | |
| 3484636 | 11 STUD (M10X1.5X70-MM) | 4 | |
| 3508541 | 12 BRACKET | 1 | |
| 3562122 | 13 DUCT (COMPRESSOR) | 1 | |
| 3565345 | 14 HOSE | 1 | |
| 4508002 | 15 LINE AS | 1 | |
| 3P0647 | SEAL-O-RING | 2 | |
| 9N1756 | SEAL-O-RING | 1 | |
| 4508003 | 16 LINES GP-TURBOCHARGER OIL | 1 | |
| 3P0647 | SEAL-O-RING | 2 | |
| 4322374 | 17 LINE AS | 1 | |
| 3570617 | 18 GASKET | 1 | |
| 3659909 | 19 LINES GP-TURBOCHARGER AIR | 1 | |
| 3740185 | 20 LINES GP-TURBOCHARGER | 1 | |
| 4322376 | 21 LINE AS | 1 | |
| 4430589 | 22 TURBOCHARGER | 1 | |
| 3875265 | 23 TURBOCHARGER | 1 | |
| 3875266 | 24 DUCT | 1 | |
| 6I0217 | 25 BOLT (M8X1.25X20-MM) | 4 | |
| 6I0254 | 26 BOLT (M8X1.25X30-MM) | 2 | |
| 6I0563 | 27 NUT (M10X1.5-THD) | 12 | |
| 3179229 | 28 CLAMP-HOSE | 2 | |
| 1978419 | 29 GASKET | 1 | |
| 4508004 | 30 ADAPTER AS | 1 | |
| 0335879 | SEAL-O-RING | 1 | |
| 4510548 | 31 BOLT | 2 | |
| 5285652 | KIT-TURBOCHARGER REPAIR | 1 |
