System And Components
461-5075 TURBOCHARGER GPS/N D8T1-UP
Group No: 461-5075 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1015115 | 1 STUD (M10X1.5X40-MM) | 4 | |
| 1031912 | 2 STUD (M10X1.5X30-MM) | 4 | |
| 1243815 | 3 BOLT (M8X1.25X16-MM) | 1 | |
| 2235664 | 4 BELLOWS | 1 | |
| 2412634 | 5 CLAMP-V BAND | 3 | |
| 3179229 | 6 CLAMP-HOSE | 2 | |
| 3293723 | 7 GASKET | 1 | |
| 3435910 | 8 CLAMP-V BAND | 1 | |
| 3484636 | 9 STUD (M10X1.5X70-MM) | 4 | |
| 3508541 | 10 BRACKET | 1 | |
| 3562122 | 11 DUCT (COMPRESSOR) | 1 | |
| 3565345 | 12 HOSE | 1 | |
| 3740185 | 13 LINES GP-TURBOCHARGER | 1 | |
| 4573636 | 14 TURBOCHARGER AS | 1 | |
| 4795828 | 15 TURBOCHARGER AS | 1 | |
| 4878468 | 15A RING | 1 | |
| 6I0563 | 16 NUT (M10X1.5-THD) | 12 |
