System And Components
281-3642 LINES GP-COOLINGS/N KCS1-UP; LJY1-UP
Group No: 281-3642 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1440367 | 1 CLAMP-HOSE | 2 | |
| 8T4984 | 2 CLAMP-HOSE | 2 | |
| 2041071 | 4 CLIP (LOOP) | 2 | |
| 2302866 | 5 HOSE | 1 | |
| 3263862 | 6 HOSE-RADIATOR (UPPER) | 1 | |
| 3263863 | 7 HOSE-RADIATOR (LOWER) | 1 | |
| 3263892 | 8 HOSE (AFTERCOOLER, HIGH TEMPERATURE) | 1 | |
| 3545095 | 9 PLATE | 1 | |
| 3545169 | 10 PLATE AS | 1 | |
| 3545170 | 11 PIPE AS (AFTERCOOLER, HIGH TEMPERATURE) | 1 | |
| 3545185 | 12 PLATE AS | 1 | |
| 7Y6215 | PLATE | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 4512180 | 13 BOLT (M16X2X35-MM) | 2 | |
| 3969448 | 14 HOSE (AFTERCOOLER, LOW TEMPERATURE) | 1 | |
| 1322155 | 15 U-BOLT | 2 | |
| 1845394 | 16 CLIP (LOOP) | 1 | |
| 5P1076 | 17 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P4116 | 18 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X0515 | 19 WASHER-HARD (17X35X5-MM THK) | 2 | |
| 7X7729 | 20 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4189 | 23 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4244 | 24 NUT (M12X1.75-THD) | 8 | |
| 8T4985 | 25 CLAMP-HOSE | 9 |
