System And Components
528-2076 LINES GP-DIESEL EXHAUST FLUIDS/N KCS20001-UP; LJY20001-UP
Group No: 528-2076 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 6W7293 | 2 GROMMET | 1 | |
| 7K1181 | 3 STRAP-CABLE | 5 | |
| 2042281 | 4 STRAP-CABLE | 10 | |
| 2048000 | 5 MOUNTING-CABLE TIE | 10 | |
| 3535128 | 6 ADAPTER AS | 1 | |
| 6V1230 | ELBOW | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3893719 | 7 ELBOW AS | 2 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 0905725 | ELBOW | 1 | |
| 3920810 | 8 TEE AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 1180911 | TEE-O-RING PORT | 1 | |
| 3976454 | 9 HOSE | 1 | |
| 4190013 | 10 PLATE AS | 1 | |
| 4216178 | 11 CONNECTOR | 1 | |
| 4317853 | 12 PLATE AS | 1 | |
| 7T1099 | LINK | 1 | |
| 4510408 | 13 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 1155411 | ELBOW | 1 | |
| 4510409 | 14 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 8T0119 | ELBOW | 1 | |
| 4510437 | 15 ADAPTER AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 8T0151 | ADAPTER | 1 | |
| 9X2133 | 16 HOSE (388-CM) | ||
| 4590577 | 17 VALVE AS-BALL | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4832234 | 18 HOSE | 1 | |
| 3652227 | 19 HOSE AS | 1 | |
| 1004336 | 20 CLIP (LOOP) | 8 | |
| 1S0994 | 21 CLIP (LOOP) | 2 | |
| 3675537 | 22 CLIP (LOOP) | 2 | |
| 6S8620 | 23 CLAMP-HOSE | 6 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 1757141 | 25 NUT-HEX FLANGE (M10X1.5-THD) | 6 | |
| 8T4136 | 26 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 27 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 28 BOLT (M10X1.5X30-MM) | 2 | |
| 3985756 | 29 INSULATION-BULK (90-CM) | ||
| 4525759 | 30 TAPE | ||
| 6V8523 | 31 HOSE (17-CM) | ||
| 4231984 | 32 HOSE (20.9-IN) | ||
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 6 |
