System And Components
377-8302 PANEL GP-SWITCH -REFUELING PUMPS/N KCS1-UP; LJY1-UP
Group No: 377-8302 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0857329 | 1 SPACER (9X19X30-MM THK) | 1 | |
| 1495050 | 2 RELAY (24-VOLT)(REFUELING PUMP, START) | 1 | |
| 1495050 | 2A RELAY (24-VOLT)(REFUELING PUMP, STOP) | 1 | |
| 2130772 | 3 SWITCH AS-MAGNETIC (24-VOLT) | 1 | |
| 2381594 | 4 SWITCH GP-PUSH BUTTON (REFUELING PUMP, START) | 1 | |
| 2381596 | 5 SWITCH GP-PUSH BUTTON (REFUELING PUMP, STOP) | 1 | |
| 3778304 | 6 BRACKET AS | 1 | |
| 3778306 | 7 COVER AS | 1 | |
| 4354367 | 8 HARNESS AS-PUMP (REFUELING PUMP) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 3S2093 | STRAP-CABLE | 11 | |
| 1160128 | SEAL | 1 | |
| 1211038 | HOUSING-RECEPTACLE | 1 | |
| 1211039 | TERMINAL (MALE) | 2 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 2L8065 | TERMINAL-RING (10-GA TO 12-GA, NO. 8 SCREW) | 1 | |
| 2L8067 | TERMINAL-RING (10-GA TO 12-GA, 1/4-IN SCREW) | 2 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 1 | |
| 2L8077 | TERMINAL-RING (14-GA TO 16-GA, 1/4-IN SCREW) | 1 | |
| 1495051 | CONNECTOR-RECEPTACLE | 2 | |
| 1495069 | TERMINAL-BLADE (14-GA TO 20-GA) | 4 | |
| 1495070 | TERMINAL-BLADE (16-GA TO 20-GA) | 4 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 2 | |
| 3245679 | DIODE | 1 | |
| 1043601 | 9 SCREW-MACHINE (M5X0.8X25-MM) | 2 | |
| 1566175 | 10 CLIP (LADDER) | 1 | |
| 3S2093 | 11 STRAP-CABLE | 1 | |
| 5C9553 | 12 BOLT (M6X1X16-MM) | 5 | |
| 7K1181 | 13 STRAP-CABLE | 1 | |
| 8T0328 | 14 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 9X2480 | 15 BOLT (M6X1X45-MM) | 1 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 6 |
