System And Components
Assembly
100%

336-6007 WIRING GP-CAB -QUICK COUPLERS/N KCS1-UP

Group No: 336-6007 · Commonality
Part NumberPart NameQty
7K11811 STRAP-CABLE8
25971802 COVER1
32804013 BRACKET1
33658804 SWITCH GP-TOGGLE (QUICK COUPLER)1
36901785 HARNESS AS-CAB1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)5
3S2093STRAP-CABLE9
7Y3951TERMINAL-BLADE (14-GA)2
7Y3952PLUG-CONNECTOR (2-PIN)1
8T8737PLUG-SEAL53
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1261767PIN-CONNECTOR (14-GA TO 16-GA)2
2304009PLUG AS-CONNECTOR (12-PIN)1
2647034SEAL-CONNECTOR1
2397356PLUG AS-CONNECTOR (12-PIN)1
2647034SEAL-CONNECTOR1
2434510RECEPTACLE AS-CONNECTOR (12-PIN)1
2725000RECEPTACLE AS-CONNECTOR (12-PIN)1
1673542RECEPTACLE-CONNECTOR (5-PIN)1
1673543TERMINAL (MALE)5
3245684RECEPTACLE AS-CONNECTOR (12-PIN)1
9X20426 SCREW-TRUSS HEAD (M6X1X12-MM)2
