System And Components
358-5972 CYLINDER GP-BOOMS/N KCS1-UP; LJY1-UP
Group No: 358-5972 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4695 | 1 LOCKNUT (M80X2-THD) | 1 | |
| 4958212 | 2 SEAL AS | 1 | |
| 1659290 | 3 SEAL-LIP TYPE | 1 | |
| 1884217 | 4 RING | 2 | |
| 1884218 | 5 RING | 1 | |
| 2426833 | 6 RING-SEAL | 1 | |
| 3585973 | 7 CYLINDER AS | 1 | |
| 2417280 | 7A BUSHING | 1 | |
| 3585983 | 8 ROD AS | 1 | |
| 2847354 | 8A BUSHING | 1 | |
| 3588523 | 9 PISTON | 1 | |
| 3588524 | 10 HEAD | 1 | |
| 3597191 | 11 STOP | 1 | |
| 0951633 | 12 SEAL-O-RING | 1 | |
| 1140760 | 13 BUSHING | 1 | |
| 3246438 | 14 SEAL-BUFFER | 1 | |
| 3246439 | 15 SEAL-U-CUP | 1 | |
| 7Y4669 | 16 RING-BACKUP | 1 | |
| 7Y4672 | 17 RING-RETAINING | 1 | |
| 7Y4673 | 18 RING-BACKUP | 1 | |
| 7Y5215 | 19 BOLT-SOCKET HEAD (M24X3X90-MM) | 8 | |
| 5185133 | KIT-SEAL (BOOM CYLINDER) | 1 |
