System And Components
375-1722 CYLINDER GP-STICKS/N KCS1-UP; LJY1-UP
Group No: 375-1722 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4956 | 1 LOCKNUT (M90X2-THD) | 1 | |
| 1038345 | 2 RING-RETAINING | 1 | |
| 1076579 | 3 RING | 1 | |
| 1915644 | 4 BUSHING | 1 | |
| 1915648 | 5 SEAL-LIP TYPE | 1 | |
| 2316843 | 6 RING-SEAL | 1 | |
| 3249484 | 7 SEAL-BUFFER | 1 | |
| 3249486 | 8 SEAL-U-CUP | 1 | |
| 3574704 | 9 CYLINDER AS | 1 | |
| 2909183 | 9A BUSHING | 1 | |
| 3574713 | 10 ROD AS | 1 | |
| 2909183 | 10A BUSHING | 1 | |
| 3588525 | 11 PISTON | 1 | |
| 3751723 | 12 HEAD | 1 | |
| 3597188 | 13 STOP | 1 | |
| 3597192 | 14 STOP | 1 | |
| 0950930 | 15 RING-RETAINING (EXTERNAL) | 2 | |
| 1400240 | 16 SEAL-O-RING | 1 | |
| 1915604 | 17 RING | 2 | |
| 1915605 | 18 RING | 1 | |
| 1915643 | 19 RING-RETAINING | 1 | |
| 1915647 | 20 RING-BACKUP | 1 | |
| 3751732 | 21 RING-BACKUP | 2 | |
| 7Y5239 | 22 BOLT-SOCKET HEAD (M24X3X100-MM) | 8 | |
| 5062322 | 23 SEAL AS | 1 | |
| 5185137 | KIT-SEAL (STICK CYLINDER) | 1 |
