Assembly
100%

318-5898 LINES GP-AUXILIARY HYDRAULIC -BOOM, HIGH PRESSURES/N KCS1-UP; LJY1-UP

Group No: 318-5898 · Commonality
Part NumberPart NameQty
17379161 CLAMP-HALF16
21665782 PLATE2
21665793 TUBE AS1
21665804 TUBE AS1
25364415 PLATE4
32309146 PLATE2
32309187 TUBE GP-HYDRAULIC (BOOM)1
1P37057A SEAL-RECTANGULAR1
7X05847B WASHER-HARD (13.5X20.5X2-MM THK)4
8T41847C BOLT (M12X1.75X45-MM)4
32539237D TUBE AS1
32539247E TUBE AS1
32539258 TUBE GP-HYDRAULIC (BOOM)1
1P37058A SEAL-RECTANGULAR1
7X05848B WASHER-HARD (13.5X20.5X2-MM THK)4
8T41848C BOLT (M12X1.75X45-MM)4
32539288D TUBE AS1
32539298E TUBE AS1
35680779 HOSE AS2
1P370410 SEAL-RECTANGULAR4
1P370511 SEAL-RECTANGULAR2
1P576712 FLANGE-HALF8
8T413913 BOLT (M12X1.75X30-MM)8
447170314 BOLT (M16X2X120-MM)8
7X058415 WASHER-HARD (13.5X20.5X2-MM THK)8
8T418416 BOLT (M12X1.75X45-MM)12
8T419417 BOLT (M12X1.75X50-MM)20
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)36
8T495619 BOLT (M12X1.75X35-MM)4
451217520 WASHER-HARD (17.5X30X3.5-MM THK)8
