318-5899 LINES GP-AUXILIARY HYDRAULIC -REACH BOOM, MEDIUM PRESSURES/N KCS1-UP; LJY1-UP

Group No: 318-5899 · Commonality
Part NumberPart NameQty
18798331 PLATE1
19366622 PLATE1
20270213 CLIP2
26871124 CLIP2
28876415 CLIP AS2
29437946 CLIP AS2
29437957 CLIP AS2
29437988 PLATE1
29437999 PLATE1
325393010 CLIP AS2
325393211 CLIP2
325393312 TUBE AS1
325393613 TUBE AS1
325393914 TUBE GP-HYDRAULIC (BOOM)1
7J9108SEAL-O-RING1
325394515 TUBE GP-HYDRAULIC (BOOM)1
7J9108SEAL-O-RING1
093129116 CLAMP4
6V839817 SEAL-O-RING4
7J910818 SEAL-O-RING2
447170819 BOLT (M16X2X80-MM)2
7Y373220 CLIP4
8T412121 WASHER-HARD (11X21X2.5-MM THK)4
8T413322 NUT (M10X1.5-THD)4
8T413923 BOLT (M12X1.75X30-MM)16
8T418524 BOLT (M10X1.5X50-MM)4
8T419425 BOLT (M12X1.75X50-MM)4
8T422326 WASHER-HARD (13.5X25.5X3-MM THK)26
8T424427 NUT (M12X1.75-THD)8
8T464828 BOLT (M12X1.75X70-MM)2
451217529 WASHER-HARD (17.5X30X3.5-MM THK)2
8T418430 BOLT (M12X1.75X45-MM)4
468460733 CLIP AS2
468461034 CLIP AS2
