System And Components
318-5933 LINES GP-AUXILIARY HYDRAULIC -MASS BOOM, HIGH PRESSURES/N KCS1-UP; LJY1-UP
Group No: 318-5933 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1737916 | 1 CLAMP-HALF | 16 | |
| 2166578 | 2 PLATE | 2 | |
| 2166579 | 3 TUBE AS | 1 | |
| 2166580 | 4 TUBE AS | 1 | |
| 2536441 | 5 PLATE | 4 | |
| 3230914 | 6 PLATE | 2 | |
| 3410182 | 7 TUBE AS | 1 | |
| 3410183 | 8 TUBE AS | 1 | |
| 3410184 | 9 TUBE AS | 1 | |
| 3410185 | 10 TUBE AS | 1 | |
| 3568077 | 11 HOSE AS | 2 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 4 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 4 | |
| 1P5767 | 14 FLANGE-HALF | 8 | |
| 8T4139 | 15 BOLT (M12X1.75X30-MM) | 8 | |
| 4471703 | 16 BOLT (M16X2X120-MM) | 8 | |
| 7X0584 | 17 WASHER-HARD (13.5X20.5X2-MM THK) | 16 | |
| 8T4184 | 18 BOLT (M12X1.75X45-MM) | 20 | |
| 8T4194 | 19 BOLT (M12X1.75X50-MM) | 20 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 36 | |
| 8T4956 | 21 BOLT (M12X1.75X35-MM) | 4 | |
| 4512175 | 22 WASHER-HARD (17.5X30X3.5-MM THK) | 8 |
