319-9807 LINES GP-BOOM -REACHS/N KCS1-UP; LJY1-UP

Group No: 319-9807 · Commonality
Part NumberPart NameQty
9F21671 SCREW-PURGE (3/8-24X1.164-IN)4
12411072 GROMMET3
12958743 GROMMET10
13857094 GROMMET3
19604825 CLIP12
20763986 TUBE GP-HYDRAULIC (BOOM)1
19604806A TUBE AS1
19604816B TUBE AS1
1P37046C SEAL-RECTANGULAR1
8T41836D BOLT (M12X1.75X40-MM)4
8T42236E WASHER-HARD (13.5X25.5X3-MM THK)4
32001277 TUBE AS1
32001298 TUBE GP-HYDRAULIC (BOOM)1
32001318A TUBE AS1
19604788B TUBE AS1
1P37048C SEAL-RECTANGULAR1
8T41838D BOLT (M12X1.75X40-MM)4
8T42238E WASHER-HARD (13.5X25.5X3-MM THK)4
35008069 HOSE AS1
239187210 HOSE AS1
356921611 TUBE GP-HYDRAULIC (BOOM)1
1P370611A SEAL-RECTANGULAR1
8T419311B BOLT (M16X2X50-MM)4
9X825711C WASHER (17.5X30X3.5-MM THK)4
359849912 TUBE AS1
359850013 TUBE AS1
124110814 CLIP8
1P370415 SEAL-RECTANGULAR4
1P370516 SEAL-RECTANGULAR2
1P576717 FLANGE-HALF4
5P807718 FLANGE-HALF4
8T413919 BOLT (M12X1.75X30-MM)4
447170720 BOLT (M16X2X60-MM)20
8T418321 BOLT (M12X1.75X40-MM)8
8T419422 BOLT (M12X1.75X50-MM)8
8T422323 WASHER-HARD (13.5X25.5X3-MM THK)24
8T495624 BOLT (M12X1.75X35-MM)4
451217525 WASHER-HARD (17.5X30X3.5-MM THK)20
6H361526 PLUG-PROTECTION4
