System And Components
321-0159 LINES GP-BOOM -STICK LOAD CONTROLS/N KCS1-UP; LJY1-UP
Group No: 321-0159 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 6 | |
| 5005221 | 2 HOSE AS | 1 | |
| 1434294 | 3 HOSE AS | 2 | |
| 1795235 | 4 CLIP | 2 | |
| 1795254 | 5 PLATE | 2 | |
| 1936662 | 6 PLATE | 1 | |
| 2825717 | 7 PLATE | 1 | |
| 3253954 | 8 CLIP | 1 | |
| 3504249 | 9 TUBE AS | 1 | |
| 1495452 | 10 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 5Q4212 | 11 CLIP | 2 | |
| 6V8398 | 12 SEAL-O-RING | 2 | |
| 6V9168 | 13 NUT (11/16-16-THD) | 2 | |
| 8T4139 | 14 BOLT (M12X1.75X30-MM) | 6 | |
| 4471704 | 15 BOLT (M16X2X90-MM) | 2 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 2825741 | 17 CLAMP AS-LOWER | 2 | |
| 8T5001 | 18 BOLT (M12X1.75X130-MM) | 2 | |
| 4512175 | 19 WASHER-HARD (17.5X30X3.5-MM THK) | 2 | |
| 4684636 | 20 CLIP AS | 1 | |
| 4I9523 | 21 BAND-MARKER (BLUE, L3) | 2 | |
| 1335813 | 22 BAND-MARKER (GRAY, P) | 2 |
