System And Components
358-7469 LINES GP-BOOM CYLINDER -BOOM LOAD CONTROL, RHS/N KCS1-UP; LJY1-UP
Group No: 358-7469 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4655185 | 1 SUPPORT AS | 1 | |
| 1491738 | 2 CLIP | 2 | |
| 2631964 | 4 VALVE GP-LOAD CONTROL (BOOM CYLINDER) | 1 | |
| 3922349 | 5 TUBE AS | 1 | |
| 3922350 | 6 TUBE AS | 1 | |
| 4658766 | 7 SUPPORT AS | 1 | |
| 3922368 | 8 PIPE AS | 1 | |
| 3926948 | 9 CLIP-SADDLE | 2 | |
| 1488336 | 10 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488341 | 11 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488361 | 12 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1P3703 | 13 SEAL-RECTANGULAR | 2 | |
| 1P3704 | 14 SEAL-RECTANGULAR | 1 | |
| 7J9108 | 15 SEAL-O-RING | 1 | |
| 4533454 | 16 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 4 | |
| 4575821 | 19 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 1083819 | 21 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 | |
| 1729966 | 22 BOLT (M12X1.75X65-MM) | 8 |
