System And Components
460-0369 LINES GP-DRAIN -HYDRAULIC OILS/N KCS1-UP; LJY1-UP
Group No: 460-0369 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2048271 | 1 HOSE AS | 1 | |
| 3508388 | 2 SPACER (11X25X65-MM THK) | 1 | |
| 4495735 | 3 BLOCK | 1 | |
| 1178568 | 4 NUT-BULKHEAD (1-7/8-12-THD) | 1 | |
| 1180166 | 5 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 1488323 | 6 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 1488335 | 7 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 4J0525 | 8 SEAL-O-RING | 1 | |
| 5P7468 | 9 CLIP (SLOT) | 1 | |
| 5P7469 | 10 CLIP (TAB) | 1 | |
| 5P8444 | 11 GROMMET (37-MM ID) | 1 | |
| 7X2543 | 12 BOLT (M10X1.5X120-MM) | 2 | |
| 7Y3195 | 13 GROMMET | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4198 | 15 BOLT (M10X1.5X100-MM) | 1 |
