System And Components
385-3080 LINES GP-FRONT -IMPLEMENT, SWING, TRAVELS/N KCS1-UP; LJY1-UP
Group No: 385-3080 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2489810 | 1 HOSE AS | 1 | |
| 3259102 | 2 HOSE AS | 1 | |
| 3259106 | 3 HOSE AS | 1 | |
| 3618983 | 4 HOSE AS | 1 | |
| 3660831 | 5 HOSE AS | 1 | |
| 4181796 | 6 HOSE AS | 1 | |
| 4181799 | 7 HOSE AS | 1 | |
| 4181803 | 8 HOSE AS | 1 | |
| 4181806 | 9 HOSE AS | 1 | |
| 5071202 | 10 TUBE AS | 1 | |
| 5071230 | 11 HOSE AS | 1 | |
| 1017397 | 12 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 4 | |
| 1017404 | 13 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 1053477 | 14 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 8 | |
| 1081781 | 15 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 8 | |
| 1488357 | 16 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1P3702 | 17 SEAL-RECTANGULAR | 4 | |
| 1P3703 | 18 SEAL-RECTANGULAR | 11 | |
| 1P3704 | 19 SEAL-RECTANGULAR | 4 | |
| 1P5767 | 20 FLANGE-HALF | 6 | |
| 6V0400 | 21 FLANGE-HALF | 10 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4184 | 23 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4194 | 24 BOLT (M12X1.75X50-MM) | 12 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 32 | |
| 8T9403 | 26 FLANGE-HALF | 4 |
