System And Components
485-1065 LINES GP-PILOT -1-WAY, ELEC CONT, MECH RLFS/N KCS1-UP; LJY1-UP
Group No: 485-1065 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I1783 | 1 HOSE AS | 1 | |
| 4I5933 | 2 HOSE AS | 1 | |
| 4I9521 | 3 BAND-MARKER (RED, L1) | 2 | |
| 4I9522 | 4 BAND-MARKER (YELLOW, L2) | 2 | |
| 4I9524 | 5 BAND-MARKER (BROWN, L4) | 2 | |
| 4I9525 | 6 BAND-MARKER (ORANGE, R1) | 2 | |
| 4I9527 | 7 BAND-MARKER (GREEN, R3) | 2 | |
| 7K1181 | 8 STRAP-CABLE | 7 | |
| 7Y4199 | 9 HOSE AS | 1 | |
| 1241008 | 10 GUARD | 1 | |
| 1335813 | 11 BAND-MARKER (GRAY, P) | 2 | |
| 1488336 | 12 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488435 | 13 TEE AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1504027 | 14 TEE AS | 2 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1645546 | 15 TEE AS | 1 | |
| 3E7410 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2597430 | 16 VALVE GP-SOLENOID (PRESSURE REDUCING) | 1 | |
| 2827106 | 17 GROMMET | 1 | |
| 3029635 | 18 HOSE AS | 2 | |
| 3402965 | 19 HOSE AS | 1 | |
| 3636134 | 20 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3543864 | ADAPTER-FILTER | 1 | |
| 4191172 | 21 SUPPORT AS | 1 | |
| 4545075 | 22 SENSOR GP-PRESSURE (STICK IN) | 1 | |
| 4545075 | 22A SENSOR GP-PRESSURE (STICK OUT) | 1 | |
| 1488305 | 23 ADAPTER AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 1488378 | 24 ELBOW AS | 7 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1645567 | 25 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1646874 | 26 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | FITTING | 1 | |
| 6V0852 | 27 CAP-DUST | 2 | |
| 8T4121 | 28 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T5005 | 30 BOLT (M10X1.5X70-MM) | 2 | |
| 8T6870 | 31 BOLT (M8X1.25X70-MM) | 2 |
