System And Components
383-9328 LINES GP-PUMP -MAIN HYDRAULICS/N KCS1-UP; LJY1-UP
Group No: 383-9328 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4222164 | 1 PIPE | 1 | |
| 3853051 | 2 HOSE | 1 | |
| 4222163 | 3 PIPE | 1 | |
| 3853055 | 4 SUPPORT AS | 1 | |
| 4194256 | 5 HOSE AS | 2 | |
| 1132003 | 6 BOLT-SOCKET HEAD (M16X2X40-MM) | 4 | |
| 1488347 | 7 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488407 | 8 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1P4578 | 9 FLANGE-HALF | 2 | |
| 1P5767 | 10 FLANGE-HALF | 4 | |
| 4J0522 | 11 SEAL-O-RING | 1 | |
| 5H4020 | 12 COVER | 1 | |
| 6V9746 | 13 SEAL-O-RING | 2 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4194 | 15 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4186 | 16 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 4533446 | 18 BOLT (M12X1.75X35-MM) | 4 | |
| 4471709 | 19 BOLT (M16X2X45-MM) | 4 | |
| 9F7283 | 20 SEAL-O-RING | 1 | |
| 9M3786 | 21 SEAL-O-RING | 1 | |
| 9X6654 | 22 CLAMP-HOSE | 4 | |
| 4512175 | 23 WASHER-HARD (17.5X30X3.5-MM THK) | 8 | |
| 4512182 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 4 |
