System And Components
319-9823 LINES GP-RETURN -SMARTBOOMS/N KCS1-UP; LJY1-UP
Group No: 319-9823 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 8 | |
| 1646874 | 2 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | FITTING | 1 | |
| 1785996 | 3 HOSE AS | 1 | |
| 3632467 | 4 HOSE AS | 1 | |
| 3302358 | 5 HOSE AS | 2 | |
| 3302361 | 6 HOSE AS | 2 | |
| 3350512 | 7 VALVE GP-MANUAL (BOOM LOAD CONTROL) | 1 | |
| 3386971 | 8 SENSOR GP-PRESSURE (HYDRAULIC OIL)(OVERLOAD WARNING) | 1 | |
| 1488347 | 9 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488382 | 10 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T0404 | ELBOW | 1 | |
| 1503036 | 11 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 8T4176 | 12 BOLT (M12X1.75X90-MM) | 2 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 2 |
