System And Components
317-4789 LINES GP-TRAVEL MOTORS/N KCS1-UP
Group No: 317-4789 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0812 | 1 HOSE AS | 2 | |
| 7K1181 | 2 STRAP-CABLE | 4 | |
| 1087118 | 3 GROMMET | 2 | |
| 1504044 | 4 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1779 | CONNECTOR | 1 | |
| 2391892 | 5 HOSE AS | 4 | |
| 2866824 | 6 HOSE AS | 2 | |
| 2967072 | 7 GROMMET | 2 | |
| 1488327 | 8 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488336 | 9 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488388 | 10 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8629 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1504033 | 11 ADAPTER AS | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 6V9846 | TEE | 1 | |
| 1P3703 | 12 SEAL-RECTANGULAR | 8 | |
| 6V0400 | 13 FLANGE-HALF | 24 | |
| 8T4184 | 14 BOLT (M12X1.75X45-MM) | 48 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 48 |
