System And Components
355-5668 MOTOR GP-TRAVELS/N KCS1-20207; LJY1-20074
Group No: 355-5668 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1T0936 | 1 PLUG-ORIFICE | 1 | |
| 4B4158 | 2 SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 6V3382 | 3 SEAL-LIP TYPE | 1 | |
| 8J2559 | 4 PLATE-WARNING (OIL FILL) | 1 | |
| 0874786 | 5 ADAPTER | 1 | |
| 1086503 | 6 PISTON AS | 9 | |
| 1184057 | 7 SPRING | 9 | |
| 1241541 | 8 PIN | 2 | |
| 1241561 | 9 SPRING-BRAKE | 20 | |
| 1373708 | 10 RETAINER | 1 | |
| 1673855 | 11 SHAFT | 1 | |
| 1673857 | 12 KEY | 1 | |
| 1673858 | 13 KEY | 1 | |
| 1673859 | 14 PLATE-CAM | 1 | |
| 1673862 | 15 PLATE-RETAINER | 1 | |
| 1673863 | 16 BALL | 1 | |
| 1673865 | 17 PLATE-SEPARATOR | 5 | |
| 1673866 | 18 PLATE-FRICTION | 4 | |
| 1673867 | 19 PLATE-PORT | 1 | |
| 1673868 | 20 PISTON-BRAKE | 1 | |
| 1673872 | 21 SPOOL | 1 | |
| 1701612 | 22 SEAL | 2 | |
| 1701626 | 23 RING-BACKUP | 1 | |
| 1701627 | 24 RING-BACKUP | 1 | |
| 1734063 | 25 BARREL AS-MOTOR | 1 | |
| 1734066 | 26 SPACER (63.05X79.8X7-MM THK) | 1 | |
| 1757436 | 27 VALVE | 1 | |
| 1757887 | 28 DOWEL | 2 | |
| 1806769 | 29 BEARING AS | 1 | |
| 1806770 | 30 BEARING AS | 1 | |
| 1865175 | 31 PLUG | 1 | |
| 1937901 | 32 BODY AS | 1 | |
| 1241555 | PLUG | 4 | |
| 2716377 | 33 HEAD AS | 1 | |
| 0965916 | SEAT | 2 | |
| 1241555 | PLUG | 4 | |
| 2744512 | 34 SEAT | 1 | |
| 2744513 | 35 RETAINER | 2 | |
| 3453744 | 36 PISTON-ACTUATOR | 1 | |
| 0951572 | 37 SEAL-O-RING | 2 | |
| 0951585 | 38 SEAL-O-RING | 1 | |
| 0951596 | 39 SEAL-O-RING | 1 | |
| 0951700 | 40 SEAL-O-RING | 2 | |
| 0957380 | 41 SPRING | 1 | |
| 0963978 | 42 SPRING | 1 | |
| 0965919 | 43 RING-BACKUP | 2 | |
| 0997030 | 44 RING-BACKUP | 1 | |
| 1701616 | 45 SEAL | 1 | |
| 2D6642 | 46 BALL | 2 | |
| 2M9780 | 47 SEAL-O-RING | 1 | |
| 2R1236 | 48 RING-RETAINING (LOCK, INTERNAL) | 1 | |
| 3D2824 | 49 SEAL-O-RING | 2 | |
| 3K0360 | 50 SEAL-O-RING | 2 | |
| 4K4284 | 51 RING-RETAINING | 1 | |
| 6V5192 | 52 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 4 | |
| 7Y5219 | 53 SEAL-O-RING | 2 | |
| 8T2393 | 54 BOLT-SOCKET HEAD (M16X2X60-MM) | 8 | |
| 9S8005 | 55 PLUG (3/4-16-THD) | 2 | |
| 9S8008 | 56 PLUG (1-1/16-12-THD) | 2 | |
| 2720290 | KIT-SEAL (TRAVEL MOTOR) | 1 |
