System And Components
377-4950 PUMP GP-MAIN HYDRAULICS/N KCS1-UP; LJY1-UP
Group No: 377-4950 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D6695 | 1 SEAL-O-RING | 2 | |
| 0060136 | 2 KEY (SQUARE) | 1 | |
| 1094496 | 3 BEARING-SPECIAL ROLLER | 4 | |
| 1184057 | 4 SPRING | 18 | |
| 1468991 | 5 SPACER (29X38X1.57-MM THK) | 1 | |
| 1673863 | 6 BALL | 2 | |
| 1734066 | 7 SPACER (63.05X79.8X7-MM THK) | 2 | |
| 1757887 | 8 DOWEL | 4 | |
| 2366919 | 9 SEAL-O-RING | 2 | |
| 2463393 | 10 BARREL AS-PUMP | 2 | |
| 4355276 | 11 PLATE-PORT | 2 | |
| 2738315 | 12 SEAL-O-RING | 1 | |
| 2822429 | 13 SENSOR GP-POSITION (SWASHPLATE) | 2 | |
| 3560857 | 14 PLATE-SENSOR | 2 | |
| 3774951 | 15 BODY | 1 | |
| 3774952 | 16 COVER | 1 | |
| 3774953 | 17 COVER | 2 | |
| 3774955 | 18 SEAL-LIP TYPE | 1 | |
| 3774956 | 19 CASE | 1 | |
| 3774957 | 20 SHAFT-DRIVE | 1 | |
| 3774958 | 21 SHAFT-DRIVEN | 1 | |
| 3774959 | 22 GEAR | 2 | |
| 3774960 | 23 HEAD GP-PUMP | 2 | |
| 3774965 | 24 SWASHPLATE AS | 1 | |
| 8T4956 | BOLT (M12X1.75X35-MM) | 2 | |
| 3988911 | 24A BEARING | 1 | |
| 3988918 | BLOCK | 1 | |
| 3774968 | 25 FLANGE | 1 | |
| 3774969 | 26 BEARING | 2 | |
| 3774970 | 27 BEARING | 2 | |
| 3774971 | 28 IMPELLER | 1 | |
| 3779067 | 29 PUMP GP-GEAR | 1 | |
| 1086503 | 30 PISTON AS | 18 | |
| 3898872 | 32 LINK | 4 | |
| 3909470 | 33 BLOCK-PORT | 1 | |
| 3921856 | 34 SWASHPLATE AS | 1 | |
| 8T4956 | BOLT (M12X1.75X35-MM) | 2 | |
| 3988911 | 34A BEARING | 1 | |
| 3988918 | BLOCK | 1 | |
| 3992640 | 35 COVER | 1 | |
| 0941875 | 36 DOWEL | 6 | |
| 0941882 | 37 PLUG | 6 | |
| 0950929 | 38 RING-RETAINING | 2 | |
| 0950946 | 39 RING-RETAINING | 2 | |
| 1297979 | 41 DOWEL | 6 | |
| 1899763 | 42 SEAL-O-RING | 2 | |
| 3080042 | 43 DOWEL-BUSHING | 4 | |
| 3J1907 | 44 SEAL-O-RING | 1 | |
| 5D5958 | 45 SEAL-O-RING | 2 | |
| 6F7061 | 46 DOWEL | 4 | |
| 6V3907 | 47 SEAL-O-RING | 1 | |
| 6V5200 | 48 RING-RETAINING | 2 | |
| 6V8243 | 49 RING-RETAINING | 1 | |
| 6V8757 | 50 RING-RETAINING | 2 | |
| 7M8485 | 51 SEAL-O-RING | 2 | |
| 7X2488 | 52 BOLT (M20X2.5X160-MM) | 1 | |
| 7X2564 | 53 BOLT (M20X2.5X90-MM) | 2 | |
| 7X2566 | 54 BOLT (M20X2.5X110-MM) | 3 | |
| 7Y5219 | 55 SEAL-O-RING | 2 | |
| 8C8545 | 56 BOLT-SOCKET HEAD (M5X0.8X20-MM) | 12 | |
| 8M1279 | 57 COVER-PROTECTION | 1 | |
| 8T0267 | 58 BOLT-SOCKET HEAD (M6X1X12-MM) | 5 | |
| 8T3016 | 59 WASHER (5.3X10X1-MM THK) | 4 | |
| 8T4137 | 60 BOLT (M10X1.5X20-MM) | 10 | |
| 8T4139 | 61 BOLT (M12X1.75X30-MM) | 10 | |
| 8T4184 | 62 BOLT (M12X1.75X45-MM) | 11 | |
| 8T7338 | 63 BOLT (M16X2X45-MM) | 5 | |
| 9S4181 | 64 PLUG (1-5/16-12-THD) | 2 | |
| 9S4191 | 65 PLUG (9/16-18-THD) | 1 | |
| 9T2584 | 66 RING-RETAINING (INTERNAL) | 1 | |
| 1673862 | 67 PLATE-RETAINER | 2 |
