System And Components
323-7464 VALVE GP-RELIEF -PILOT OPERATEDS/N KCS1-UP; LJY1-UP
Group No: 323-7464 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I3510 | 1 SPRING | 1 | |
| 7F2050 | 2 LOCKNUT (3/4-16-THD) | 1 | |
| 6I6795 | 3 SPRING | 1 | |
| 0951786 | 4 RING-BACKUP | 1 | |
| 6V8218 | 5 SEAL-O-RING | 1 | |
| 6V8978 | 6 SEAL-O-RING | 1 | |
| 4802133 | 7 VALVE AS-RELIEF | 1 | |
| 1195398 | 7A SCREEN-FILTER (RELIEF VALVE) | 1 | |
| 3526864 | 8 SEAT-VALVE | 1 | |
| 1710037 | 9 VALVE | 1 | |
| 2597848 | 10 SLEEVE | 1 | |
| 2597849 | 11 PISTON | 1 | |
| 2597850 | 12 SLEEVE | 1 | |
| 2597851 | 13 ADJUSTER | 1 | |
| 2872499 | 14 NUT (M24X2-THD) | 1 | |
| 3D2824 | 15 SEAL-O-RING | 1 | |
| 0951579 | 16 SEAL-O-RING | 1 | |
| 0951584 | 17 SEAL-O-RING | 1 | |
| 0951587 | 18 SEAL-O-RING | 1 | |
| 0951590 | 19 SEAL-O-RING | 1 |
