System And Components
343-9449 BOOM GP -GRADE CONTROLS/N KCS1-UP; LJY1-UP
Group No: 343-9449 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I5005 | 1 PLATE | 2 | |
| 0930074 | 2 SHIM (1-MM THK) | 1 | |
| 0930349 | 3 WASHER (22X60X6-MM THK) | 1 | |
| 1132963 | 4 PIN AS | 1 | |
| 1473957 | 5 SHIM (0.5-MM THK) | 1 | |
| 1661489 | 6 SHIM (2-MM THK) | 2 | |
| 1661490 | 7 SHIM (2-MM THK) | 2 | |
| 1661498 | 8 SEAL-LIP TYPE | 2 | |
| 1928321 | 9 PIN | 1 | |
| 3240938 | 10 PLATE | 1 | |
| 3595743 | 11 PIN AS | 1 | |
| 4838165 | 12 BOOM & BEARING AS | 1 | |
| 2285621 | 12A BUSHING | 2 | |
| 0930366 | 13 SPACER (93X130X12-MM THK) | 1 | |
| 4I4978 | 15 SPACER (113X150X8-MM THK) | 2 | |
| 4512176 | 16 WASHER-HARD (22X35X3.5-MM THK) | 1 | |
| 4512180 | 17 BOLT (M16X2X35-MM) | 6 | |
| 4532844 | 18 BOLT (M20X2.5X30-MM) | 1 | |
| 4471709 | 19 BOLT (M16X2X45-MM) | 2 | |
| 4512175 | 20 WASHER-HARD (17.5X30X3.5-MM THK) | 8 |
