System And Components
236-8415 LINKAGE GP-BUCKET -DB-FAMILY, WITH LIFTING EYES/N KCS1-UP; LJY1-UP
Group No: 236-8415 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 5 | |
| 0930349 | 2 WASHER (22X60X6-MM THK) | 1 | |
| 1661496 | 3 SEAL-LIP TYPE | 4 | |
| 1893922 | 4 PIN | 1 | |
| 2012771 | 5 WASHER (26X90X8-MM THK) | 1 | |
| 2012836 | 6 BOLT (M24X3X200-MM) | 1 | |
| 2417129 | 7 LINK | 1 | |
| 2417150 | 8 LINK AS | 1 | |
| 2512552 | 9 PIN AS | 1 | |
| 2512557 | 10 PIN | 1 | |
| 2512558 | 11 PIN AS | 1 | |
| 2543025 | 12 LINK & BEARING AS | 1 | |
| 2417280 | 12A BUSHING | 2 | |
| 2285615 | 12B BUSHING | 2 | |
| 3678468 | 13 SEAL-O-RING | 2 | |
| 3678469 | 14 SEAL-O-RING | 2 | |
| 1661488 | 15 SHIM (2-MM THK) | 2 | |
| 1661495 | 16 SEAL-LIP TYPE | 2 | |
| 1865649 | 17 BOLT (M20X2.5X160-MM) | 1 | |
| 4512185 | 18 NUT (M24X3-THD) | 2 | |
| 4512176 | 19 WASHER-HARD (22X35X3.5-MM THK) | 1 | |
| 4512184 | 20 NUT (M20X2.5-THD) | 2 | |
| 4512177 | 21 WASHER-HARD (26X44X4-MM THK) | 1 | |
| 4532854 | 22 BOLT (M24X3X50-MM) | 1 | |
| 4532845 | 23 BOLT (M20X2.5X40-MM) | 1 |
