342-2277 BUCKET GP-SEVERE SERVICE ROCK -DB-FAMILYS/N KCS1-UP; LJY1-UP
Group No: 342-2277 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3422279 | 1 BUCKET AS | 1 | |
| 3483115 | 2 EDGE AS | 1 | |
| 3091116 | 2A ADAPTER-TIP (K-110, 2-STRAP, LH) | 1 | |
| 3091114 | 2B ADAPTER-TIP (K-110, 2-STRAP, CENTER) | 1 | |
| 3091115 | 2C ADAPTER-TIP (K-110, 2-STRAP, RH) | 1 | |
| 8P9770 | 2D PLATE | 1 | |
| 3483122 | 3 PLATE-WEAR | 1 | |
| 3483146 | 4 PLATE-WEAR | 4 | |
| 3483080 | 5 PLATE-WEAR | 2 | |
| 3483151 | 6 PLATE-WEAR | 2 | |
| 3483234 | 7 PLATE AS-HINGE | 1 | |
| 2C9259 | 8 PLATE-IDENTIFICATION (CAT) | 2 | |
| 3125694 | 9 SETSCREW (1/4-20X0.25-IN) | 1 |
