System And Components
340-6709 AIR CONDITIONER & MOUNTING GPS/N KCS1-UP; LJY1-UP
Group No: 340-6709 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 2358874 | 2 SENSOR-TEMPERATURE (AMBIENT AIR) | 1 | |
| 3406510 | 3 BLOCK GP-JUNCTION | 1 | |
| 1133468 | SEAL-O-RING | 1 | |
| 1217063 | SEAL-O-RING | 1 | |
| 2931139 | SWITCH AS-PRESSURE (REFRIGERANT) | 1 | |
| 3406700 | 4 BRACKET | 1 | |
| 3639494 | 5 PANEL AS-CONTROL (AIR CONDITIONER, HEATER) | 1 | |
| 3639495 | 6 HARNESS AS-HEATER & AIR COND | 1 | |
| 4981163 | 7 AIR CONDITIONER GP | 1 | |
| 1195026 | 8 SCREW-PAN HEAD (10-16X0.63-IN) | 4 | |
| 5C9553 | 9 BOLT (M6X1X16-MM) | 2 | |
| 8T4222 | 10 WASHER-PLATED (11X32X2.5-MM THK) | 6 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4191 | 13 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4971 | 14 BOLT (M6X1X30-MM) | 1 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 3 |
