System And Components
316-8992 DUCT GP-CAB AIRS/N KCS1-UP; LJY1-UP
Group No: 316-8992 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1282135 | 1 SCREW-TRUSS HEAD (M6X1X13-MM) | 6 | |
| 2299028 | 2 CLIP | 1 | |
| 3276484 | 3 DUCT (FRESH AIR) | 1 | |
| 3276533 | 4 FRAME GP-AIR FILTER (CAB) | 1 | |
| 3276534 | 5 DUCT AS-VENTILATION (REAR) | 1 | |
| 3276535 | 6 DUCT (VENT, FRONT) | 1 | |
| 3276536 | 7 DUCT (STRAIGHT) | 1 | |
| 3276537 | 8 DUCT AS (FLOOR) | 1 | |
| 3276618 | 9 FILTER ELEMENT-CAB AIR (AIR INTAKE) | 1 | |
| 3361206 | 10 DUCT | 1 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 1 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 1 |
