System And Components
346-7922 HATCH GP-ROOFS/N KCS1-UP; LJY1-UP
Group No: 346-7922 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0856449 | 1 PACKING | 3 | |
| 1613694 | 2 CATCH | 1 | |
| 1892693 | 3 BRACKET AS | 1 | |
| 1892694 | 4 BRACKET AS | 1 | |
| 3467906 | 5 VISOR | 1 | |
| 3467907 | 6 BRACKET | 1 | |
| 3467908 | 7 BRACKET AS | 1 | |
| 3467924 | 8 LOCK AS | 1 | |
| 3406592 | 9 HINGE AS | 2 | |
| 3573914 | 10 SEAL | 1 | |
| 2719408 | 11 SCREW-TRUSS HEAD (M5X0.8X10-MM) | 8 | |
| 1717477 | 12 NUT (M6X1-THD) | 2 | |
| 4I1260 | 13 PACKING | 2 | |
| 4I4361 | 14 RETAINER | 3 | |
| 6I5342 | 15 NUT (M8X1.25-THD) | 4 | |
| 9X2045 | 16 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 3440869 | 17 FILM-INSTRUCTION (ALTERNATE EXIT) | 1 |
