Assembly
100%

324-5657 HORN GP-ELECTRICS/N KCS1-UP; LJY1-UP

Group No: 324-5657 · Commonality
Part NumberPart NameQty
7K11811 STRAP-CABLE1
7Y39192 HORN AS (24-VOLT, LOW TONE)1
0950826LOCKWASHER2
0957930SCREW-MACHINE (M4X0.7X6-MM)2
7Y39203 HORN AS (24-VOLT, HIGH TONE)1
0950826LOCKWASHER2
0957930SCREW-MACHINE (M4X0.7X6-MM)2
32456584 HARNESS AS-ALARM (HORN)1
3S2093STRAP-CABLE1
9W0852PIN-CONNECTOR (14-GA TO 16-GA)2
2L8065TERMINAL-RING (10-GA TO 12-GA, NO. 8 SCREW)2
1257875TUBE-HEAT SHRINK (7.44-MM DIA)
2L8075TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW)2
1257874TUBE-HEAT SHRINK (5.72-MM DIA)
2434505RECEPTACLE AS-CONNECTOR (2-PIN)1
46357915 BRACKET AS1
13257896 CLIP (LADDER)1
8T42247 WASHER-HARD (8.8X16X2-MM THK)3
8T42008 BOLT (M8X1.25X16-MM)3
