System And Components
319-1183 INSTALLATION GP-RADIOS/N KCS1-UP; LJY1-UP
Group No: 319-1183 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 17 | |
| 1858284 | 2 COVER | 1 | |
| 2382216 | 3 SWITCH AS-ROCKER (RADIO MUTE) | 1 | |
| 1673542 | RECEPTACLE-CONNECTOR (5-PIN) | 1 | |
| 1673543 | TERMINAL (MALE) | 5 | |
| 4752681 | 4 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 3423295 | 5 HARNESS AS-RADIO | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 13 | |
| 3S2093 | STRAP-CABLE | 20 | |
| 7Y3950 | TERMINAL-BLADE (14-GA TO 20-GA) | 2 | |
| 7Y3951 | TERMINAL-BLADE (14-GA) | 2 | |
| 7Y3952 | PLUG-CONNECTOR (2-PIN) | 1 | |
| 7Y3953 | CONNECTOR-RECEPTACLE | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1027965 | TERMINAL (14-GA TO 20-GA) | 4 | |
| 1636803 | PLUG-CONNECTOR (5-PIN) | 1 | |
| 1636808 | CONNECTOR-RECEPTACLE | 1 | |
| 1636809 | TERMINAL (MALE) | 7 | |
| 1673487 | WEDGE-PLUG LOCK (5-PIN) | 1 | |
| 2305010 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2647032 | SEAL-CONNECTOR | 1 | |
| 2312295 | PLUG AS-CONNECTOR (8-PIN) | 1 | |
| 2647033 | SEAL-CONNECTOR | 1 | |
| 3422975 | CAP-CONNECTOR (8-PIN) | 1 | |
| 9X2042 | 6 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 3531892 | 7 BRACKET AS | 1 | |
| 9X2044 | 8 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 |
