System And Components
346-8062 PARTS GP-DOORS/N KCS10001-UP; LJY1-UP
Group No: 346-8062 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1516703 | 1 HANDLE-PULL | 1 | |
| 1516704 | 2 CAP | 2 | |
| 1613639 | 3 HANDLE AS | 1 | |
| 1640515 | 4 JOINT | 1 | |
| 1677039 | 5 GROMMET | 1 | |
| 1785574 | 6 SPACER | 2 | |
| 1858180 | 7 SCREW (M6X1X16-MM) | 3 | |
| 2597354 | 9 COVER | 1 | |
| 3835650 | 10 WINDOW GP-DOOR | 1 | |
| 3346526 | 11 SPACER | 2 | |
| 3346527 | 12 SPACER | 2 | |
| 3346528 | 13 SEAL AS | 1 | |
| 1519497 | CLIP | 23 | |
| 3346531 | 14 SEAL AS | 1 | |
| 3346530 | CLIP | 5 | |
| 3346534 | 15 HOOK | 1 | |
| 3346535 | 16 LATCH AS | 1 | |
| 1640514 | CLIP (10.5-MM) | 1 | |
| 1640519 | CLIP (13-MM) | 1 | |
| 3346536 | 17 COVER | 1 | |
| 3346537 | 18 HANDLE AS | 1 | |
| 2014391 | CLIP | 1 | |
| 3346538 | 19 BUSHING-RUBBER | 1 | |
| 3468063 | 20 GLASS | 1 | |
| 0962622 | 21 SCREW-MACHINE (M4X0.7X8-MM) | 2 | |
| 0963884 | 22 NUT-SPRING (M8X1.25-THD) | 2 | |
| 1018899 | 23 SCREW AS (M6X1.0X16-MM) | 2 | |
| 1018900 | 24 SCREW AS (M6X1X20-MM) | 2 | |
| 1519461 | 25 SPACER | 2 | |
| 1566643 | 26 COVER | 2 | |
| 1785573 | 27 SPACER | 3 | |
| 1892690 | 28 HANDLE | 1 | |
| 4I4286 | 29 KNOB | 1 | |
| 9X2042 | 30 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 |
