System And Components
316-8895 SUSPENSION GP-SEAT -AIRS/N KCS1-UP; LJY1-UP
Group No: 316-8895 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1983899 | 1 SCREW-BUTTON HEAD (M8X1.25X20-MM) | 4 | |
| 2457895 | 2 KIT-CLIP (SEAT) | 1 | |
| 3168897 | 3 KIT-CONSOLE ADJUSTMENT (OPERATOR CONTROLS) | 1 | |
| 3835705 | BRACKET | 1 | |
| 3835742 | 3A BUSHING | 4 | |
| 3276646 | 4 KIT-CYLINDER (DAMPENER) | 1 | |
| 3276648 | 5 KIT-ADJUSTER (SEAT POSITION) | 1 | |
| 3334157 | 6 KIT-SEAT SUSPENSION (AIR) | 1 | |
| 3334158 | 7 KIT-COVER (SUSPENSION) | 1 | |
| 5957229 | 8 KIT-VALVE (AIR SEAT) | 1 | |
| 3334178 | 9 NUT-SPECIAL | 1 | |
| 3334180 | 10 SCREW-BUTTON HEAD (M8X1.25X20-MM) | 6 |
