System And Components
327-6625 WINDOW GP-CAB -FRONT, UPPERS/N KCS10001-UP; LJY1-UP
Group No: 327-6625 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1519557 | 1 STOP-RUBBER | 2 | |
| 1388454 | 2 SCREW-TRUSS HEAD (M4X0.7X10-MM) | 2 | |
| 3346388 | 3 WINDOW GP-CAB (FRONT, UPPER) | 1 | |
| 3346492 | 4 STRIKER GP-LATCH (WINDOW) | 1 | |
| 3346497 | 5 SHEET AS | 1 | |
| 3346499 | 6 BRACKET AS | 1 | |
| 3346501 | 7 STRIKER AS | 1 | |
| 3346504 | 8 SHIM (2-MM THK) | 1 | |
| 3346505 | 9 BRACKET AS | 1 | |
| 3346507 | 10 SEAL AS | 1 | |
| 3346508 | 11 CABLE AS | 1 | |
| 3346509 | 12 GUIDE AS | 1 | |
| 0992374 | 13 BOLT-SOCKET HEAD (M5X0.8X12-MM) | 1 | |
| 1176306 | 14 SWITCH (WINDOW LOWER LIMIT) | 1 | |
| 9X2041 | 15 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X2042 | 16 SCREW-TRUSS HEAD (M6X1X12-MM) | 10 | |
| 5C8312 | 17 NUT (M4X0.7-THD) | 1 | |
| 3639373 | 18 SPACER | 2 | |
| 4305703 | 19 SHIM (2-MM THK) | 1 | |
| 9X2044 | 20 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 |
