434-5249 MODULE GP-COOLINGS/N F5L1-UP; LRT1-UP

Group No: 434-5249

Part Number	Part Name	Qty
0964035	1 CLIP	1
2331449	2 PIN	2
3477615	3 FRAME AS	1
3477616	4 FRAME AS	1
3477617	5 FRAME AS	1
3477620	6 MOUNT	8
3477623	7 CONNECTOR	1
3489965	8 SPRING AS-GAS (AFTERCOOLER CORE)	1
3550451	9 LATCH AS	2
3550452	10 SEAL-AIR	4
3550453	11 SEAL-AIR	1
3550455	12 SEAL-AIR	2
3550456	13 PLATE	1
3550457	14 BRACKET AS	1
3550458	15 BRACKET AS	1
3550459	16 SEAL-AIR	1
3550461	17 SEAL-AIR	1
3550463	18 SEAL-AIR	1
3550465	19 BRACKET AS	1
3550467	20 PLATE	2
3550469	21 RUBBER	2
3550470	22 FRAME AS	1
3550454	23 SEAL-AIR	3
4345250	24 CORE AS-RADIATOR	1
3324192	SEAL-O-RING	1
3550468	PLUG-DRAIN	1
3786187	BOSS-MOUNTING	4
3786197	COVER	4
4345251	25 CORE AS-OIL COOLER	1
4345252	26 CORE AS-AFTERCOOLER	1
4756666	27 FRAME AS	1
1007740	28 RING-RETAINING	2
1156433	29 WASHER (11X50X6-MM THK)	8
1549023	30 VALVE-SAMPLING	1
1570670	31 CAP-DUST	1
3K0360	32 SEAL-O-RING	1
5C7261	33 NUT (M8X1.25-THD)	2
5P1076	34 WASHER-HARD (13.5X30X4-MM THK)	16
5P4116	35 WASHER-HARD (8.8X20.5X2-MM THK)	2
5C9553	36 BOLT (M6X1X16-MM)	4
6V9027	37 SEAL-O-RING	1
7X7729	38 WASHER (11X25X3-MM THK)	2
8T4121	39 WASHER-HARD (11X21X2.5-MM THK)	12
8T4133	40 NUT (M10X1.5-THD)	8
8T4136	41 BOLT (M10X1.5X25-MM)	6
8T4182	42 BOLT (M10X1.5X45-MM)	4
8T4186	43 BOLT (M10X1.5X40-MM)	8
8T4192	44 BOLT (M12X1.75X25-MM)	16
8T4195	45 BOLT (M10X1.5X30-MM)	2
8T4223	46 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4956	47 BOLT (M12X1.75X35-MM)	2
9X8256	48 WASHER (6.6X12X2-MM THK)	4
7Y1976	49 HOSE-WATER (22-CM)
