388-6702 PANEL GP-CIRCUIT BREAKERS/N FEB1-UP; RDE1-UP

Group No: 388-6702

Part Number	Part Name	Qty
3E8320	1 PLATE-INSTRUCTION (BATTERY)	1
3S2093	2 STRAP-CABLE	1
7N0718	3 SWITCH GP-DISCONNECT (BATTERY)	1
7Y5499	4 BLOCK AS-TERMINAL	1
9G8451	5 BLOCK AS	1
1H3244	LOCKWASHER	1
4B4276	WASHER (7X16X1.6-MM THK)	2
4L7124	BOLT (1/4-20X1.25-IN)	1
6V8185	NUT (1/4-20-THD)	2
1251302	6 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY)	1
1412759	7 FUSE (5-AMPERE)	1
1712205	8 CIRCUIT BREAKER AS (40-AMPERE)(GLOW PLUG)	1
1712208	9 CIRCUIT BREAKER AS (60-AMPERE)(ALTERNATOR)	1
1712210	10 CIRCUIT BREAKER AS (80-AMPERE)(MAIN)	1
4E5724	WASHER (7X12X1-MM THK)	2
8T0122	NUT-FULL (1/4-28-THD)	2
1H3244	LOCKWASHER	2
2381506	11 COVER	1
2382279	12 BAR-BUS	1
2382280	13 WIRE AS	1
2418368	14 SWITCH GP-MAGNETIC (24-VOLT)(GLOW PLUG RELAY)	1
2510303	15 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)(0.2-M)
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	2
2510304	16 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)(0.2-M)
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	2
2667379	17 STRAP-CABLE	1
3245804	18 WIRE AS	1
3245805	19 WIRE AS	1
3245808	20 HOLDER AS-FUSE	1
8T8737	PLUG-SEAL	1
9W0852	PIN-CONNECTOR (14-GA TO 16-GA)	1
2L8078	TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW)	1
2434505	RECEPTACLE AS-CONNECTOR (2-PIN)	1
3886773	21 BRACKET AS-PANEL	1
6V9632	NUT-WELD (M6X1-THD)	10
3886775	22 WIRE AS	1
3886776	23 WIRE AS	1
5C9553	24 BOLT (M6X1X16-MM)	6
5P4115	25 WASHER-HARD (7.2X19X2-MM THK)	4
6V5645	26 SCREW-MACHINE (10-32X0.87-IN)	6
8T0328	27 WASHER-HARD (5.5X10X1-MM THK)	6
8T4171	28 BOLT (M6X1X12-MM)	4
8T4970	29 BOLT (M6X1X14-MM)	6
9X8256	30 WASHER (6.6X12X2-MM THK)	12
