System And Components
398-7007 PANEL GP-SWITCH -CONSOLES/N RDE1-UP
Group No: 398-7007
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 1709324 | 2 LAMP AS-INDICATOR (24-VOLT, 3-WATT) | 1 | |
| 2341158 | 3 COVER | 1 | |
| 2552751 | 4 SWITCH GP-START (ENGINE, KEY) | 1 | |
| 2677976 | 5 PANEL | 1 | |
| 3987013 | 6 HARNESS AS-PANEL | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 3 | |
| 7Y3951 | TERMINAL-BLADE (14-GA) | 2 | |
| 7Y3952 | PLUG-CONNECTOR (2-PIN) | 1 | |
| 7Y3966 | TERMINAL AS | 1 | |
| 7Y3962 | TERMINAL-BULLET (MALE) | 1 | |
| 7Y3964 | TUBE | 1 | |
| 7Y3967 | TERMINAL AS | 1 | |
| 7Y3963 | TERMINAL-BULLET (FEMALE) | 1 | |
| 7Y3965 | TUBE | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1211168 | CONNECTOR-RECEPTACLE | 1 | |
| 1211173 | TERMINAL (MALE) | 14 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 4 | |
| 1532540 | TERMINAL (FEMALE) | 10 | |
| 1532541 | PLUG-CONNECTOR (10-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2382366 | TERMINAL (MALE) | 2 | |
| 3988931 | 7 COVER | 1 | |
| 0966166 | 8 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1195026 | 9 SCREW-PAN HEAD (10-16X0.63-IN) | 4 | |
| 6V9491 | 10 SCREW-MACHINE (M4X0.7X20-MM) | 4 |
