Assembly
100%

421-1431 CONSOLE GP-OPERATORS/N FEB1-UP; RDE1-UP

Group No: 421-1431
Part NumberPart NameQty
17619161 GROMMET2
17854222 GROMMET2
17854233 GROMMET2
18581614 INSULATOR2
23588935 SUPPORT2
23588946 SUPPORT2
42114347 CONSOLE GP-OPERATOR (LH)1
25973488 CONSOLE GP-OPERATOR (RH)1
8T41219 WASHER-HARD (11X21X2.5-MM THK)4
8T419510 BOLT (M10X1.5X30-MM)4
9X204611 SCREW-TRUSS HEAD (M6X1X35-MM)8
9X204512 SCREW-TRUSS HEAD (M6X1X20-MM)12
7K118113 STRAP-CABLE4
122961714 GUARD2
475417315 INSULATOR2
5P592716 SEAL (0.12-M EACH)
