System And Components
339-6917 LINES GP-ENGINE OIL DRAINS/N RBD1-UP
Group No: 339-6917
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1108827 | 1 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 2774567 | 3 ADAPTER | 1 | |
| 3514241 | 4 HOSE AS | 1 | |
| 3514239 | 5 PLATE AS | 1 | |
| 3514081 | 6 PLATE AS | 1 | |
| 2V2043 | 7 NUT-BULKHEAD (1-5/8-12-THD) | 1 | |
| 2287092 | 8 SEAL-O-RING | 1 | |
| 2792252 | 9 SEAL-O-RING | 1 | |
| 3196216 | 10 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 5P7466 | 11 CLIP (SLOT) | 1 | |
| 5P7467 | 12 CLIP (TAB) | 1 | |
| 5P8112 | 13 GROMMET | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4172 | 17 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 3570147 | 19 FILM-IDENTIFICATION (OIL FILL, READ OMM) | 1 |
