System And Components
389-1535 MODULE GP-COOLINGS/N RBD1-UP
Group No: 389-1535
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X7729 | 1 WASHER (11X25X3-MM THK) | 40 | |
| 3393871 | 2 SEAL-AIR | 4 | |
| 2330060 | 3 FILM-IDENTIFICATION (LIFT EYE LOCATION) | 2 | |
| 3355459 | 4 CORE AS-RADIATOR | 1 | |
| 3355462 | 5 PIN | 16 | |
| 3364433 | 6 PIN | 8 | |
| 8T4137 | 8 BOLT (M10X1.5X20-MM) | 16 | |
| 3395904 | 9 CORE AS-OIL COOLER | 1 | |
| 3399707 | 10 SEAL-AIR | 1 | |
| 3399709 | 11 SEAL-AIR | 1 | |
| 3479742 | 13 CORE AS-AFTERCOOLER | 1 | |
| 3891575 | 14 FRAME AS | 1 | |
| 3487808 | 15 BRACKET AS | 1 | |
| 3891577 | 16 FRAME AS | 1 | |
| 3487810 | 17 BRACKET AS | 1 | |
| 1891943 | 19 LOCKNUT (M10X1.5-THD) | 12 | |
| 6E5293 | 20 BOLT (M10X1.5X210-MM) | 12 |
