System And Components
428-7044 TURBOCHARGER GPS/N W7N1-99999
Group No: 428-7044
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I4045 | 1 BOLT (M10X1.5X75-MM) | 4 | |
| 1004454 | 2 NUT (M8X1.25-THD) | 4 | |
| 1142583 | 3 STUD (M8X1.25X37-MM) | 4 | |
| 1243815 | 4 BOLT (M8X1.25X16-MM) | 1 | |
| 3179229 | 5 CLAMP-HOSE | 2 | |
| 3426435 | 6 PIPE-EXHAUST | 1 | |
| 3435908 | 7 CLAMP-V BAND | 1 | |
| 3435910 | 8 CLAMP-V BAND | 2 | |
| 3484636 | 9 STUD (M10X1.5X70-MM) | 4 | |
| 3487736 | 10 GASKET | 1 | |
| 3565345 | 11 HOSE | 1 | |
| 5672084 | 12 BRACKET | 1 | |
| 3589191 | 13 ELBOW | 1 | |
| 3601584 | 14 LINES GP-TURBOCHARGER AIR | 1 | |
| 4213007 | 15 TURBOCHARGER | 1 | |
| 5567924 | 16 TURBOCHARGER AS | 1 | |
| 4878468 | 16A RING | 1 | |
| 6I0563 | 17 NUT (M10X1.5-THD) | 4 |
