Assembly
100%

360-6190 WIRING GP-COMMUNICATION -MACHINE SECURITY SYSTEMS/N RAF1-UP

Group No: 360-6190
Part NumberPart NameQty
32803911 SWITCH GP-START (ENGINE)1
36901732 HARNESS AS-POWER1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)2
3S2093STRAP-CABLE2
8T8737PLUG-SEAL2
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)6
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1552270KIT-CONNECTING PLUG (2-PIN)1
1552265KIT-CONNECTING PLUG (8-PIN)1
2434507RECEPTACLE AS-CONNECTOR (4-PIN)1
09661663 WASHER-HARD (4.5X9X1-MM THK)2
12821354 SCREW-TRUSS HEAD (M6X1X13-MM)1
3S20935 STRAP-CABLE1
8C75816 SCREW-MACHINE (M4X0.7X8-MM)2
