System And Components
377-7801 MODULE GP-COOLINGS/N KMK1-UP
Group No: 377-7801
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0964035 | 1 CLIP | 1 | |
| 3477623 | 2 CONNECTOR | 1 | |
| 3527779 | 3 FRAME AS | 1 | |
| 3527781 | 4 CORE AS-OIL COOLER | 1 | |
| 3699786 | 5 SEAL-AIR | 3 | |
| 3699787 | 6 SEAL-AIR | 2 | |
| 3699793 | 7 SEAL-AIR | 4 | |
| 3699796 | 8 MOUNT | 8 | |
| 3777802 | 9 FRAME AS | 1 | |
| 3777803 | 10 FRAME AS | 1 | |
| 3777804 | 11 FRAME AS | 1 | |
| 3777805 | 12 PLATE AS | 1 | |
| 3777807 | 13 CORE AS-AFTERCOOLER | 1 | |
| 5M6213 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 3777809 | 14 PLATE AS | 1 | |
| 3786187 | 15 BOSS-MOUNTING | 8 | |
| 3857937 | 16 SPACER | 4 | |
| 3911493 | 17 SEAL-AIR | 1 | |
| 3911494 | 18 SEAL-AIR | 1 | |
| 3911495 | 19 SEAL-AIR | 1 | |
| 3911496 | 20 SEAL-AIR | 1 | |
| 4331678 | 21 CORE AS-RADIATOR | 1 | |
| 3324192 | SEAL-O-RING | 1 | |
| 3550468 | PLUG-DRAIN (RADIATOR) | 1 | |
| 3786187 | BOSS-MOUNTING | 4 | |
| 3786197 | COVER | 4 | |
| 3K0360 | 22 SEAL-O-RING | 1 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 6 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4186 | 25 BOLT (M10X1.5X40-MM) | 8 | |
| 8T4192 | 26 BOLT (M12X1.75X25-MM) | 16 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T5005 | 29 BOLT (M10X1.5X70-MM) | 4 | |
| 7Y1976 | 30 HOSE-WATER (21-CM) |
