System And Components
390-4279 LINES GP-AUXILIARY HYDRAULIC -MEDIUM PRESSURE, REACH BOOMS/N KMK1-UP
Group No: 390-4279
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931291 | 1 CLAMP | 2 | |
| 0931295 | 2 CLAMP | 1 | |
| 1491738 | 3 CLIP | 5 | |
| 1936606 | 4 PLATE | 2 | |
| 2479294 | 5 SUPPORT AS | 2 | |
| 2825530 | 6 TUBE AS | 1 | |
| 3729700 | 7 TUBE AS | 1 | |
| 4341099 | 8 TUBE AS | 1 | |
| 4341098 | 9 TUBE AS | 1 | |
| 3904323 | 10 CLIP AS | 1 | |
| 3905807 | 11 CLIP AS | 1 | |
| 0969986 | 12 BOLT (M12X1.75X55-MM) | 1 | |
| 1538867 | 13 CLIP | 4 | |
| 6V8398 | 14 SEAL-O-RING | 4 | |
| 7J9108 | 15 SEAL-O-RING | 2 | |
| 7X2549 | 16 BOLT (M12X1.75X100-MM) | 4 | |
| 7Y4868 | 17 CLIP | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4185 | 20 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 8T4184 | 22 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4244 | 23 NUT (M12X1.75-THD) | 4 |
