System And Components
420-4952 GAUGE GP-OIL LEVEL (DIPSTICK)S/N T4F7539-UP
Group No: 420-4952 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2097309 | 1 PLUG | 2 | |
| 3441950 | 2 CLIP (SLOT) | 2 | |
| 4953111 | 3 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3720676 | 4 BRACKET AS | 1 | |
| 4953109 | 5 GAUGE GP-OIL LEVEL (DIPSTICK) | 1 | |
| 4953110 | TUBE AS-OIL GAUGE | 1 | |
| 4953120 | GAUGE AS-OIL LEVEL (DIPSTICK) | 1 | |
| 2284947 | 6 SEAL-O-RING | 1 | |
| 3441951 | 7 CLIP (TAB) | 2 | |
| 3E4352 | 8 WASHER-HARD (8.8X20.5X2.5-MM THK) | 3 | |
| 8T4224 | 9 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 6V3940 | 10 BOLT (M8X1.25X25-MM) | 1 | |
| 5C7261 | 11 NUT (M8X1.25-THD) | 1 | |
| 6V5217 | 12 BOLT (M8X1.25X20-MM) | 2 |
