System And Components
375-7819 SUPPORT & MOUNTING GPS/N RBF1-UP
Group No: 375-7819 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3433857 | 1 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 5 | |
| 3440611 | 2 BRACKET | 2 | |
| 3519838 | 3 BRACKET | 1 | |
| 3848654 | 4 PLATE AS-MOUNTING | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 20 | |
| 7T1099 | LINK | 5 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 10 | |
| 1837121 | 5 BOLT (M10X1.5X35-MM) | 12 | |
| 2470553 | 6 BOLT (M8X1.25X30-MM) | 2 | |
| 3118193 | 7 BOLT (M10X1.5X45-MM) | 5 | |
| 3118366 | 8 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 3388453 | 9 BOLT (M8X1.25X40-MM) | 2 | |
| 3441199 | 10 WASHER-HARD (11X21X2.5-MM THK) | 17 |
