System And Components
473-1585 LINES GP-FUELS/N RBF1-UP
Group No: 473-1585 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0379 | 1 VALVE-MANUAL (FUEL) | 1 | |
| 4I7889 | 2 SPACER (11X25X45-MM THK) | 1 | |
| 5I3876 | 3 GROMMET | 3 | |
| 0963872 | 4 GROMMET | 1 | |
| 2130793 | 5 GROMMET | 2 | |
| 3328593 | 6 VALVE AS-BALL (FUEL) | 1 | |
| 1562525 | VALVE-SHUTOFF | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1759106 | 7 ELBOW AS | 1 | |
| 6V9001 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1911782 | 8 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 1911783 | 9 SPACER (8.5X12.7X87.3-MM THK) | 2 | |
| 4I5106 | 10 GROMMET | 2 | |
| 2846206 | 11 GROMMET | 1 | |
| 3328594 | 12 ELBOW AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2681530 | ELBOW | 1 | |
| 3504851 | 13 BRACKET AS | 1 | |
| 3601693 | 14 PUMP GP-FUEL PRM & PRIM FILTER (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 3687663 | 15 HOSE | 1 | |
| 3902266 | 16 BRACKET AS | 1 | |
| 3902268 | 17 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3902288 | 18 HOSE AS | 1 | |
| 3902289 | 19 HOSE AS | 1 | |
| 5197010 | 20 HOSE AS | 1 | |
| 3902291 | 21 HOSE | 1 | |
| 4236434 | 22 SENSOR GP-LIQUID LEVEL (WATER IN FUEL) | 1 | |
| 4334617 | 23 PLATE AS | 1 | |
| 4467124 | 24 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1017404 | 25 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 5078356 | 26 CONNECTOR AS | 1 | |
| 1433158 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4391960 | 27 ADAPTER AS | 1 | |
| 2042281 | 28 STRAP-CABLE | 1 | |
| 2751442 | 31 CLIP (TAB) | 1 | |
| 2751443 | 32 CLIP (SLOT) | 1 | |
| 2751444 | 33 GROMMET | 1 | |
| 2D0388 | 34 GROMMET (25.4-MM ID) | 2 | |
| 3095131 | 35 PLUG AS | 2 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3328562 | 36 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3474416 | 37 ADAPTER | 2 | |
| 3514315 | 38 CLIP (LOOP) | 3 | |
| 3514318 | 39 CLIP (LOOP) | 2 | |
| 3514320 | 40 CLIP (LOOP) | 16 | |
| 3514321 | 41 CLIP (LOOP) | 7 | |
| 3514322 | 42 CLIP (LOOP) | 5 | |
| 3535150 | 43 CONNECTOR AS | 1 | |
| 8T1576 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3537953 | 44 GROMMET | 2 | |
| 3S2093 | 45 STRAP-CABLE | 1 | |
| 5I8307 | 46 GROMMET | 2 | |
| 5V9155 | 47 CLAMP-HOSE | 2 | |
| 6S8620 | 48 CLAMP-HOSE | 6 | |
| 3535143 | 49 ADAPTER AS | 1 | |
| 6V5653 | ELBOW (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 7X0579 | 50 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 7X2539 | 51 BOLT (M8X1.25X110-MM) | 2 | |
| 8T1889 | 52 CLIP (SLOT) | 2 | |
| 8T1890 | 53 CLIP (TAB) | 2 | |
| 8T4121 | 54 WASHER-HARD (11X21X2.5-MM THK) | 58 | |
| 8T4133 | 55 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 56 BOLT (M10X1.5X25-MM) | 18 | |
| 8T4137 | 57 BOLT (M10X1.5X20-MM) | 30 | |
| 8T5005 | 58 BOLT (M10X1.5X70-MM) | 1 | |
| 8T6869 | 59 BOLT (M8X1.25X60-MM) | 1 | |
| 8T9655 | 60 MOUNT-ISOLATION | 6 | |
| 9R8780 | 61 CLIP | 1 | |
| 9R8781 | 62 CLIP | 1 | |
| 8C3681 | 63 HOSE-DRAIN (30-CM) | ||
| 3478645 | 64 HOSE (170-CM) | ||
| 3478645 | 64A HOSE (30-CM) | ||
| 1189901 | 65 SPACER (12X20X10-MM THK) | 1 | |
| 8T4196 | 66 BOLT (M10X1.5X35-MM) | 1 | |
| 0919035 | 67 SPACER (11X25X20-MM THK) | 1 | |
| 3S8536 | 68 SPACER (0.406X0.656X0.38-IN THK) | 1 | |
| 3432385 | 69 CLIP (LOOP) | 7 |
