System And Components
499-2153 WIRING GP-VALVES/N RBF1-UP
Group No: 499-2153 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 14 | |
| 4I7889 | 2 SPACER (11X25X45-MM THK) | 2 | |
| 7K1181 | 3 STRAP-CABLE | 10 | |
| 1114836 | 4 CLIP | 1 | |
| 1160118 | 5 CLIP | 2 | |
| 2667379 | 6 STRAP-CABLE | 1 | |
| 4270045 | 7 BRACKET AS-VALVE | 1 | |
| 4512176 | 8 WASHER-HARD (22X35X3.5-MM THK) | 2 | |
| 4532845 | 9 BOLT (M20X2.5X40-MM) | 2 | |
| 5039059 | 10 HARNESS AS-VALVE | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 9 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 14 | |
| 3S2093 | STRAP-CABLE | 3 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(25-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 16 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 16 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 2434509 | RECEPTACLE AS-CONNECTOR (8-PIN) | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 8 | |
| 2697678 | 11 CLIP | 1 | |
| 1325789 | 12 CLIP (LADDER) | 5 | |
| 1343299 | 13 GROMMET | 1 | |
| 2041611 | 14 STRAP-CABLE (DUAL) | 4 | |
| 1772215 | 15 STRAP-DUAL CLAMP | 3 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4191 | 18 BOLT (M10X1.5X16-MM) | 3 | |
| 8T5005 | 19 BOLT (M10X1.5X70-MM) | 1 | |
| 8T6466 | 20 BOLT (M10X1.5X60-MM) | 1 |
